Side Tilt Carriage - Rated by the tine carriage hoisting capacity, there are four sizings of hook type blade carriages. The hook type fork carriages have been standardized.
Class I carriages are rated for cargo as much as 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for cargo up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for cargo up to 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.
The carriages for pin type blades may be different depending on the maker. Pin mounted blades could vary by the amount of offset between the fork eye and the blade. Carriage capacity will be determined by the carriage pin size and by the fork size.
